| MECHANICAL | | FORM FACTOR | Micro-ATX: 9.6” x 9.6” (244 mm x 244 mm) |
| SYSTEM | | PROCESSOR | 9th & 8th Gen Intel Coffee Lake LGA1151 Socket Processor, Core i7/i5/i3 6-core TDP Max. 95W, Core i9 8-core TDP Max 35W |
| CHIPSET | Intel® Q370 (Support RAID 0 / 1 / 5 / 10) / Intel® H310 |
| SYSTEM MEMORY |
DDR4 2666MHz / 2 x 288-pin U-DIMM / Max. 64 GB (Non-ECC) |
| GRAPHICS | Intel® HD Graphics |
| ETHERNET | Intel® I219-LM Giga LAN + Intel® I210-AT Giga LAN |
| I/O CHIPSET | Nuvoton NCT6683D |
| AUDIO | Realtek® ALC892 |
| TPM | Nuvoton NPCT750AAAYX TPM2.0 (Optional) |
| EXPANSION SLOT |
PCIe 3.0 X16 slot / 2 x PCIe 2.0 X8 slot (X4 Lanes) for Q370 / PCIe 2.0 X8 slot (X4 Lanes) for H310 |
| BIOS | 256 Mbit SPI |
| H/W MONITOR | Temperature Monitor / Voltage Monitor / Fan Monitor |
| WATCHDOG TIMER | 1~255 steps by software program |
| SMART FAN CONTROL | CPU Fan / System Fan |
| GRAPHICS | | VGA | - |
| DVI | Up to 4K (4096 x 2160) @30 Hz |
| HDMI | - |
| DISPLAYPORT | Up to 4K (4096 x 2304) @60 Hz |
| LVDS | - |
| eDP (Option) | - |
| REAR I/O | | USB | 4 x USB 3.1 Gen 2 (Q370) / 2 x USB 2.0 (Q370) / 4 x USB 2.0 (H310) / 2 x USB 3.0 (H310) |
| DISPLAY I/O | 2 x DisplayPort 1.2 / 1 x DVI-D |
| AUDIO I/O | 1 x 6-stack Audio Jack |
| LAN I/O | 2 x RJ-45 |
| SERIAL PORT | - |
| PS/2 PORT | - |
| OTHERS | - |
| INTERNAL CONNECTORS | | STORAGE | 4 x SATAIII (H310) |
| USB | 2 x USB3.0 (Q370) / 2 x USB 2.0 |
| DISPLAY I/O | - |
| AUDIO I/O | - |
| SERIAL PORT | 4 x RS232 |
| PARALLEL PORT | - |
| GPIO | - |
| FAN | 1 x 4-pin CPU Fan Header / 1 x 4-pin System Fan Header |
| POWER | 1 x 8-pin ATX Power Connector / 1 x 24-pin ATX Power Connector / 1 x AT / ATX Mode Select Jumper |
| OTHERS | 1 x Chassis Intrusion / 1 x CMOS Jumper / 1 x Front Audio Header (Mic-in & Line-out) |
| POWER REQUIREMENT | | POWER INPUT | ATX 8-pin + ATX 24-pin |
| ENVIRONMENTAL | | OPERATING TEMPERATURE | 0 ~ 60°C (32 ~140°F) |
| STORAGE TEMPERATURE | -20 ~ 70°C (-4 ~158°F) |
| OPERATING HUMIDITY | 10% ~ 95% R/H (Non-condensing) |
| CERTIFICATION | CE / FCC Class B |
| OS | | OS SUPPORT | Windows® 10 64-bit / Linux (support by request) |
| PACKING LIST | | PACKAGE | 1 x Motherboard / 1 x 50 cm SATA Cable / 1 x I/O Bracket |
