incl. 19% VAT, plus
|MB Model||– JR3288A-DG2N (1.8” SBC)|
|Part No||– HBJC924R3288DG2NS|
– Rockchip® ARM Cortex A17 RK3288 1.8GHz Quad core
– Rockchip® RK808-B
|Memory||– 2GB/1333MHz DDR3L|
|Storage||– 8GB Flash (Max 64GB)|
– 1 * REALTEK RTL8211E‐VB Gigabit LAN
– 1 * REALTEK RTL8723BS 802.11b/g/n 2.4G WIFI and BT-V4.0
|Rear Panel I/O||
– 1 * RJ45
– 4 * USB2.0
– 1 * Micro SD Socket (Front)
|Side Panel I/O||
– 1 * OTG / DC Jack
– 1 * HDMI (Max Resolution: 1920×1080@60Hz)
– 1 * Audio
– 26bit GPIO, 1* I2C
– 1* MIPI DSI
– 1* MIPI CSI
– DC 5V-3.0A
– AC 100~240V input
– RoHS, ErP Ready
– Operating Temperature: -10 ~ 60° C
– Storage Temperature: -20 ~ 65° C
– 87.0(W) x 56.0(D) x 2.9(H) mm
– Shelf: 110.0(W) x 111.1(D) x 33.6(H) mm
|OS Support||– Android 5.1, Linux Debian 9.0|
|Warranty||– 1 Year limited warranty|
