Display
|
Front Bezel
|
- IP67, NEMA 4 rugged protection, Overall
|
Display Type
|
- 15.0" With LED Backlight
|
Brightness ( cd/m²)
|
- 450 nits
|
Display Color
|
- 262K
|
Resolution
|
- 1024 x768 @ 60Hz
|
Viewing Angle (H/V)
|
- 160°/150°
|
Pixel Pitch
|
- 0.297 x 0.297 mm
|
Aspect Ratio
|
- 4:3
|
Contrast Ratio
|
- 800:1
|
Response Time
|
- 5.7 ms
|
Touch screen
|
Type
|
- 5 wires analog resistive type
|
Active Range
|
- 304.10 x 228.10mm ±0.2mm
|
Transparency
|
- 80 ±3%
|
Surface Hardness
|
- ≧ 3H (ASTM D3363, pressure 750g/45°)
|
Operating Force
|
- ≦ 80g
|
Knock test
|
- 10,000,000 times keystrokes
|
Main System
|
CPU
|
- Intel® Bay Trail-D J1900 2.0GHz/QC
|
RAM
|
- 4G 1333MHz DDR3L SAMSUNG DRAM
|
BIOS
|
- 64MB SPI Flash ROM
|
Storage
|
- 1 * 2.5” SATA HDD
- 1 * M.2 connector (2242/2260/2280)
|
Watchdog Timer
|
- 255 levels, 0~255 sec.
|
OS Support
|
- Windows 7 / 8.1 / 10 / Linux
|
I/O Connector
|
I/O Ports and Switches
|
- 4 * USB2.0
- 2 * RS232/422/485
- 1 * LAN (Intel® I211AT Gigabit LAN)
- 1 * Locking Jack 9~28V DC input
- 1 * Power button
|
Expansion Interface
|
Expansion
|
- 1 * PCI-E mini card for WIFI or 4G/3G
|
Power
|
Power Input
|
- AC version: 100~240V AC-DC 60W power adapter or
- DC version: 9~28V DC with over current protection fuse
|
Power Consumption
|
- 25W
|
Dimensions
|
Case Dimensions
|
- 365.4*289.3*50mm
|
Packing Dimensions
|
- Net Weight: KG
- Gross Weight: KG
- Color Box dimension: 476*140*460mm
|
Certifications
|
Certifications
|
- CE, FCC, IP67
|
Environment
|
Temperature
|
- Operating: -10°C ~ 60°C (with W.T. DRAM/HDD in airflow condition)
- Operating: -10°C ~ 60°C (with W.T. DRAM/HDD)
|
- Storage: -20°C ~ 65°C
|
Shock
|
- Operating: 15G,11ms duration
|
Vibration
|
- Operating: 5~500Hz/1 Grms
|
Warranty
|
Warranty
|
- The warranty of 2 years, panel the warranty of 1 year
|
