Jetway B420PADN1-A111 BoxPC (Intel N-series SoC Processor N97, 1x HDMI, 1x 2.5GE LAN, 8GB RAM) [FANLESS]

Jetway B420PADN1-A111 BoxPC (Intel N-series SoC Processor N97, 1x HDMI, 1x 2.5GE LAN, <b>8GB RAM</b>) <b>[FANLESS]</b>

Barebone !
Intel N97 !
1x HDMI !
2x Comprehensive I/O !

Powered by Intel® N97/N200 SoC Processors (formerly Alder Lake)
High-Performance Memory: Supports DDR5 SO-DIMM
4K Display: Supports HDMI 2.0b (4096×2160@60Hz) for high-resolution output
Storage & Expansion: 1 x M.2 E-Key, 1 x B+M Key paired with 1 x Nano SIM Slot
Comprehensive I/O: 2 x USB 3.2 Gen2, 2 x USB 2.0, 2 x RS-232/422/485
Enhanced Security: Supports Intel fTPM
Pre-installed with one DDR5 4800MHz, Single Channel SO-DIMM, 8GB Memory

469.00 EUR
incl. 19% VAT, plus shipping
Available in 3-7 days

SYSTEM
MB FORM FACTOR	Pico-ITX
CPU	Onboard Intel® Processor N97 (Formerly Alder Lake-N, TDP 12W) Onboard Intel® Processor N200 (Formerly Alder Lake-N, TDP 6W)
CHIPSET	Intel® SoC
MEMORY	1 x DDR5 4800MHz, Single Channel SO-DIMM, up to 32GB (8GB preinstalled)
BIOS	UEFI
WAKE ON LAN	Yes
WATCHDOG TIMER	255 Levels
SECURITY	Intel® PTT (Integrated fTPM)
RTC BATTERY	Lithium Battery
OS SUPPORT	Windows® 11 (64bit) Windows® 10 (64bit) Linux
POWER
POWER REQUIREMENT	DC-in 12V 40W Adapter: AC90~240V, DC12V/3.3A
POWER ON MODE	AT / ATX (Default) Mode
DISPLAY
GPU	Intel® UHD Graphics
HDMI	1 x HDMI 2.0b (Max Resolution: 4096 x 2160@60Hz)
AUDIO
CODEC	Realtek Audio Codec
LAN
ETHERNET	1 x RJ45 for Realtek® RTL8111H GbE
SYSTEM I/O
REAR PANEL I/O	2 x USB 3.2 Gen.1 1 x RJ45 1 x HDMI 1 x DC-in (Lockable) 2 x WIFI Antenna Holes 1 x GND Hold
FRONT PANEL I/O	2 x RS-232/422/485 2 x USB 2.0 1 x Power Button + Power LED
EXPANSION
M.2	1 x B+M-Key 2242/3042/3052 (USB 3.2/SATA III/PCIe 3.0 x2) 1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1)
SIM	1 x Nano SIM Card Slot
MECHANICAL
MOUNTING	Wall + VESA mount
DIMENSIONS (W x D x H)	129.0 (W) x 109.4 (D) x 34.0 (H) mm
NET WEIGHT	0.56 KG
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE	-20°C ~ 50°C (-4°F ~ 122°F)
STORAGE TEMPERATURE	-40°C ~ 85°C (-40°F ~ 185°F)
OPERATING HUMIDITY	10 ~ 90% Relative Humidity, Non-condensing
CERTIFICATION	CE/FCC Class A LVD
ESG DECLARATION	China RoHS CMRT Report TSCA Declaration WEEE REACH

Data sheet	Download (PDF)
Data sheet	Print view
Jetway Catalog (Rackmount)	Download (PDF)
Jetway Catalog (Barebones)	Download (PDF)
